| NEMA CONFIGURATIONS FOR STRAIGHT BLADE PLUGS AND RECEPTACLES | ||||||||||||
| DESCRIPTION | NEMA NUMBER |
15 AMPERE | 20 AMPERE | 30 AMPERE | 50 AMPERE | 60 AMPERE | ||||||
| RECEPTACLE | PLUG | RECEPTACLE | PLUG | RECEPTACLE | PLUG | RECEPTACLE | PLUG | RECEPTACLE | PLUG | |||
| 2-POLE 2-WIRE |
125V | 1 | 1-15R |
1-15P |
1-20P |
1-30P |
||||||
| 250V | 2 | 2-15P |
2-20R |
2-20P |
2-30R |
2-30P |
||||||
| 2-POLE 3-WIRE GROUNDING |
125V | 5 | 5-15R |
5-15P |
5-20R |
5-20P |
5-30R |
5-30P |
5-50R |
5-50P |
||
| 125V | 5ALT | 5ALT-20R |
||||||||||
| 250V | 6 | 6-15R |
6-15P |
6-20R |
6-20P |
6-30R |
6-30P |
6-50R |
6-50P |
|||
| 250V | 6ALT | 6ALT-20R |
||||||||||
| 277V AC | 7 | 7-15R |
7-15P |
7-20R |
7-20P |
7-30R |
7-30P |
7-50R |
7-50P |
|||
| 347V AC | 24 | 24-15R |
24-15P |
24-20R |
24-20P |
24-30R |
24-30P |
24-50R |
24-50P |
|||
| 3-POLE 3-WIRE |
125/250V | 10 | 10-20R |
10-20P |
10-30R |
10-30P |
10-50R |
10-50P |
||||
| 3Φ 250V | 11 | 11-15R |
11-15P |
11-20R |
11-20P |
11-30R |
11-30P |
11-50R |
11-50P |
|||
| 3-POLE 4-WIRE GROUNDING |
125/250V | 14 | 14-15R |
14-15P |
14-20R |
14-20P |
14-30R |
14-30P |
14-50R |
14-50P |
14-60R |
14-60P |
| 3Φ 250V | 15 | 15-15R |
15-15P |
15-20R |
15-20P |
15-30R |
15-30P |
15-50R |
15-50P |
15-60R |
15-60P |
|
| 4-POLE 4-WIRE |
3Φ Y 120/250V | 18 | 18-15R |
18-15P |
18-20R |
18-20P |
18-30R |
18-30P |
18-50R |
18-50P |
18-60R |
18-60P |
| TRAVEL TRAILER |
120V | TT | TT-30R |
TT-30P |
||||||||
